Washing unit for ritual toilet

REF.: 2500

Table trolley specially adapted for body toilets, and also for ritual toilets. It is composed of :

A stainless steel tank 304, size 200 x 80, composed of 12 removable bars of Ø 30mm (positioned on 2 HDPE racks), tank thickness 1.5 mm equipped with a draining hole Ø 70 mm towards the washing unit, or the floor drain via a stretchable hose type Etiroflex.

And a trolley base in 304 with 4 wheels Ø 150mm (2 with brakes), height adjustable from 73 to 103 cm and a declivity system (on each side of the tank) offering a very high robustness and rigidity, equipped with 2 column jacks allowing an adjustment of the height of the table and an adjustment of the declivity proclivity via a control, an emergency stop button, a battery with integrated charger (in full charge 30 up and down cycles).

Dimensions: (L x W x H): 200 x 80 x Mini 73 – Max 103cm. Load capacity: 300 Kg.

Option: 2500/L Washing unit specially adapted to collect waste water from the trolley: Unit in stainless steel 304, dimension 185 x 85 x 85.5 (W x D x H), thickness 1.2mm, including: 2 sink trays: 1 horizontal 60 x 45 x 30cm (height) and 1 lateral 24 x 24 x 15cm (height) with drain and siphon, 1 hot/cold water mixer tap with elbow control, 1 cold water hand shower with 3m long hose, and 2 HDPE side protection strips

Table trolley specially adapted for body toilets, and also for ritual toilets. It is composed of : A stainless steel tank 304, size 200 x 80, composed of 12 removable bars of Ø 30mm (positioned on 2 HDPE racks), tank thickness 1.5 mm equipped with a draining hole Ø 70 mm towards the washing unit, or the floor drain via a stretchable hose type Etiroflex. And a trolley base in 304 with 4 wheels Ø 150mm (2 with brakes), height adjustable from 73 to 103 cm and a declivity system (on each side of the tank) offering a very high robustness and rigidity, equipped with 2 column jacks allowing an adjustment of the height of the table and an adjustment of the declivity proclivity via a control, an emergency stop button, a battery with integrated charger (in full charge 30 up and down cycles). Dimensions: (L x W x H): 200 x 80 x Mini 73 – Max 103cm. Load capacity: 300 Kg. Option: 2500/L Washing unit specially adapted to collect waste water from the trolley: Unit in stainless steel 304, dimension 185 x 85 x 85.5 (W x D x H), thickness 1.2mm, including: 2 sink trays: 1 horizontal 60 x 45 x 30cm (height) and 1 lateral 24 x 24 x 15cm (height) with drain and siphon, 1 hot/cold water mixer tap with elbow control, 1 cold water hand shower with 3m long hose, and 2 HDPE side protection strips.

Packing: By unit with individual box.
