Ventilated tank for anatomical parts in laboratory and autopsy
Made of stainless steel 316, rectangular tank with slope shape at the bottom of the tank for total emptying on butterfly valve, cooling of the tank by 2 perimeter belts (heat exchange surface 1,4m²) operating pressure 3bars – inlet temperature 8°C.
Skirt with 4 adjustable feet. U-shaped suction strip at the top of the tank (height of the strip 120mm) and closing cover on top of the tank (assisted by 2 stainless steel gas springs) including 3 wire baskets with handles for easy handling.
The temperature regulation is ensured by a flow control valve at the outlet of the exchanger. Sheet metal cladding for the EF supply pipes and air extraction ducts.
Made of stainless steel 316 grain 220 (external face) and glazed 2B internal faces. Includes a PT 100 probe model IFM TM4599 for the bath.
Dimensions: external width 190 cm, rectangular tank internal dimensions (L x W x D): 178 x 60 x 60 cm – external (H extraction – tray x W x D): 200 – 98 x 190 x 72.5cm.
Made of stainless steel 316, rectangular tank with slope shape at the bottom of the tank for total emptying on butterfly valve, cooling of the tank by 2 perimeter belts (heat exchange surface 1,4m²) operating pressure 3bars – inlet temperature 8°C
Skirt with 4 adjustable feet. U-shaped suction strip at the top of the tank (height of the strip 120mm) and closing cover on top of the tank (assisted by 2 stainless steel gas springs) including 3 wire baskets with handles for easy handling. The temperature regulation is ensured by a flow control valve at the outlet of the exchanger. Sheet metal cladding for the EF supply pipes and air extraction ducts. Made of stainless steel 316 grain 220 (external face) and glazed 2B internal faces. Includes a PT 100 probe model IFM TM4599 for the bath.
Dimensions: external width 190 cm, rectangular tank internal dimensions (L x W x D): 178 x 60 x 60 cm – external (H extraction – tray x W x D): 200 – 98 x 190 x 72.5cm.
Packing: By unit with individual box.
