Electric Stair Stretcher for coffin or corpses

REF.: 1359

This trolley has been designed for the transfer of the body at home, or the coffin, for its transport to the morgue or the funeral home. It allows to go up or down stairs without effort thanks to an autonomous electric motor.

For the body is used with a lifting stretcher Ref. 470.

Its aluminium alloy structure makes it easy to manoeuvre (empty weight 22 kg). It has a lithium battery to power its 400 watt motor. The 48V battery weighs 3 kg, and can be recharged in about 1.5 hours from an external 230V / 1N~ / 50hz power supply. The battery capacity is 5Amp hour, and the trolley has a range of about 1200 (stair) steps.

The trolley is foldable for easy storage in the transport vehicle. The manoeuvrability of the trolley is guaranteed by 2 pneumatic wheels of 200mm diameter. The steps are negotiated by 2 motorised cylindrical wheels, operated by a start/stop control lever. The climbing speed is 34 steps per minute (fast mode) and 25 steps (slow mode).

Maximum step height: 21cm. Load capacity 180 Kg (maximum allowed 200kg).

Dimensions : Folded length 33cm (unfolded 45cm), Width 50,5 cm x Folded height 65,5 cm (unfolded 150cm), Empty weight 22 kg.

This trolley has been designed for the transfer of the body at home, or the coffin, for its transport to the morgue or the funeral home. It allows to go up or down stairs without effort thanks to an autonomous electric motor. For the body is used with a lifting stretcher Ref. 470. Its aluminium alloy structure makes it easy to manoeuvre (empty weight 22 kg). It has a lithium battery to power its 400 watt motor. The 48V battery weighs 3 kg, and can be recharged in about 1.5 hours from an external 230V / 1N~ / 50hz power supply. The battery capacity is 5Amp hour, and the trolley has a range of about 1200 (stair) steps. The trolley is foldable for easy storage in the transport vehicle. The manoeuvrability of the trolley is guaranteed by 2 pneumatic wheels of 200mm diameter. The steps are negotiated by 2 motorised cylindrical wheels, operated by a start/stop control lever. The climbing speed is 34 steps per minute (fast mode) and 25 steps (slow mode). Maximum step height: 21cm. Load capacity 180 Kg (maximum allowed 200kg). Dimensions : Folded length 33cm (unfolded 45cm), Width 50,5 cm x Folded height 65,5 cm (unfolded 150cm), Empty weight 22 kg.

Packing: By unit with individual box.
