Conservation Cell 4 bodies with big door, expandable to 5
Positive cold temperature for preservation of bodies at +4°c: T° range -5°c to +10°c,
60 mm thick panels, free passage door (H x W) 220 x 80 cm with 180° opening to the left or to the right, All lacquered PET55µ front door finish.
Fitting: all stainless steel 304 interior with 4 stretchers (flat Ref. 1560 or curved Ref. 1561). Refrigeration unit: Monobloc, side-mounted.
Dimensions (W x H x D) 112 x 252 x 218cm (+30cm for the unit in width)
Other possible finishes: Ref. 65481 304 stainless steel front, Ref. 75481 all 304 stainless steel, additional grey hard PVC coating (ACROVYN) on the door front.
Other Free passage: width 62 cm or 100 cm (for obese with wide curved stretcher Ref. 1571),
Extendable to 5 bodies: by adding a supplementary stretcher and a KITRAIL, ceiling unit compulsory: Ref. 55581 All lacquered PET55µ front door, Ref. 65581 304 stainless steel front, Ref. 75581 all 304 stainless steel,
Group variant: ceiling mounted or as a split system less than 15 metres away,
Cell variant: negative cold temperature -25°c to -0°c, 100 mm thick panels, dimensions (W x H x D) 120 x 260 x 230cm (+30cm for the unit in width). Ref. 55481N10 All lacquered, or Ref. 65481N10 304 stainless steel front, or Ref. 75481N10 all 304 stainless steel.
Positive cold temperature for preservation of bodies at +4°c: T° range -5°c to +10°c, 60 mm thick panels, free passage door (H x W) 220 x 80 cm with 180° opening to the left or to the right, All lacquered PET55µ front door finish. Fitting: all stainless steel 304 interior with 4 stretchers (flat Ref. 1560 or curved Ref. 1561). Refrigeration unit: Monobloc, side-mounted.
Dimensions (W x H x D) 112 x 252 x 218cm (+30cm for the unit in width)
Other possible finishes: Ref. 65481 304 stainless steel front, Ref. 75481 all 304 stainless steel, additional grey hard PVC coating (ACROVYN) on the door front.
Other Free passage: width 62 cm or 100 cm (for obese with wide curved stretcher Ref. 1571),
Extendable to 5 bodies: by adding a supplementary stretcher and a KITRAIL, ceiling unit compulsory: Ref. 55581 All lacquered PET55µ front door, Ref. 65581 304 stainless steel front, Ref. 75581 all 304 stainless steel,
Group variant: ceiling mounted or as a split system less than 15 metres away,
Cell variant: negative cold temperature -25°c to -0°c, 100 mm thick panels, dimensions (W x H x D) 120 x 260 x 230cm (+30cm for the unit in width). Ref. 55481N10 All lacquered, or Ref. 65481N10 304 stainless steel front, or Ref. 75481N10 all 304 stainless steel.
Packing: By unit on pallet
